ACSR Overhead Conductor Greases (also called ACSR anti-corrosion/filling greases) are specialized semi-solid lubricants designed for steel-core aluminum reinforced (ACSR) overhead power conductors. They are applied between the aluminum strands and steel core during manufacturing to protect and enhance performance.
sfdfshshsdfhsdh
Core Purpose & Functions
- Anti-corrosion protection: Seals out moisture, salt spray, industrial pollutants, and prevents galvanic corrosion between aluminum and steel.
- Lubrication & anti-wear: Reduces inter-strand friction, fretting wear, and vibration fatigue from wind/ice loads.
- Filling & sealing: Fills gaps between strands to block water ingress and improve structural stability.
- Thermal stability: Resists dripping, oil separation, and degradation at high operating temperatures (up to 180°C).
- Electrical compatibility: Non-conductive, does not impair current-carrying performance.
dhdhdhfdhdhss
dhsdhdfhsdhsddshsdh
Features and Benefits
》Minimizes oil bleed during normal operation and post – fault conditions of transmission lines.
》Provides superior corrosion protection for conductors in diverse environments, including coastal high – salt zones, heavy industrial pollution areas, and high – humidity and heat regions.
》Tailored formulations cover full temperature range from ambient to 240°C for transmission line operations.
》High – temperature specialized synthetic grease resists oil separation and stays stable under extreme heat.
》It has exceptional low – temperature stability, preventing cracking down to – 60°C.
》With outstanding oxidation resistance and anti – aging properties, it extends service life.
》Complies with GB/T 36292 – 2018, BS EN 50326 – 2002, and IEC 61394 – 2011 standards.
dgdshfsdfsdfhsddh
Technical Data
| Items | OPS20A120 | OPS40A120 | OPS20A180 | OPS40A180 | OPS60A180 | OPS40A240 |
| Description | 20A120 | 40A120 | 20A180 | 40A180 | 60A180 | 40A240 |
| Max. Temp. Rating | 120°C | 120°C | 180°C | 180°C | 180°C | 240°C |
| Min. Temp. Rating | 20°C | 40°C | 20°C | 40°C | 60°C | 40°C |
| Drop Point | >280°C | >280°C | >300°C | >300°C | >300°C | >330°C |
| Application | ACSR&OPGW | ACSR&OPGW | ACSR&OPGW | ACSR&OPGW | OPGW | HTLS |
| EN 50326 Compliant | Yes | Yes | Yes | Yes | Yes | Yes |
| IEC 61394 Compliant | Yes | Yes | Yes | Yes | Yes | Yes |
| IGB/T 36292 Compliant | Yes | Yes | Yes | Yes | Yes | Yes |
